2023 NEW XHDATA D-109WB FM ST/MW/LW/SW/NOAA Wireless Bluetooth Outdoor Digital Portable Global Band Radio TF Card Reader
XHDATA D-109WB version is an upgraded version of D-109
D-109WB version = D-109 version + WB Band + SOS + VOICE/MUSIC Mode + DX/LOC Mode
Key Features:
1. WBAA Emergency Weather Warning Radio: Stay informed about weather conditions and receive emergency alerts with the built-in WBAA radio function.
2. SOS Emergency Distress Sound and Light Alarm: In case of emergencies, activate the distress alarm to attract attention and seek help.
3. Wireless Cell Phone Call: Connect your wireless cell phone to the radio for convenient hands-free communication.
4. Key Lock/Display Switch: Easily lock the keys and switch the display for enhanced usability.
5. Manual Tuning and Automatic Frequency Browsing: Fine-tune your radio frequency manually or use the automatic browsing mode for quick scanning.
6. AM Bandwidth Switching and LCD Backlight: Adjust the AM bandwidth and enjoy the convenience of a permanently on LCD backlight with intelligent control.
7. Voice/Music Switch: Seamlessly switch between voice and music modes for personalized listening experience.
8. DX Remote and LOC Local Proximity Receive Mode Switching: Choose between DX remote and LOC local proximity receive modes for optimized reception.This function makes your listening signal more senstive and selective.
9. Bluetooth Function: Enjoy wireless phone calls and stream music from your Bluetooth-enabled devices.
10. Radio Memory Station Selection: Easily select and tune to your preferred radio stations, and even play Bluetooth music.
Tuning Methods:
- Direct input
- Auto scan
- Manual tuning
Power / Charging:
- Battery power: 18650 battery
- DC: 3.7V (18650) 2000mAh
- DC5V IN: DC5V / 1000mA
Specification:
Frequency range
- FM: 64-108 MHz/76-108 MHz/87-108 MHz / 87.5-108 MHz (100 KHz/10 KHz Tuning Steps)
- LW: 153-513KHz (9K/1K Tuning Steps)
- AM: 522-1620KHz (9K/1K Steps) / 520-1710KHz (10K/1K Steps)
- SW: 1711-29999KHz (5K/1K Steps)
- NOAA Weather: CH 1 162.400MHz, CH 2 162.425, CH 3 162.450, CH 4 162.475,CH 5 162.500, CH 6 162.525, CH 7 162.550
Noise limiting sensitivity
- FM: (S/N=30dB): > 2 μV
- LW: (S/N=26dB): >10mV/m
- MW:(S/N=26dB): >1mV/m
- SW:(S/N=26dB): > 18μV
Selectivity
- FM: 60dB
- LW: 60dB
- MW:60dB
- SW:60dB
Memory radio frequency
- FM: 100 pcs
- LW:100 pcs
- MW: 100 pcs
- SW: 300 pcs
More Information
- Maximum output power: 2.0W
- Headphone impedance: 16-32Ω
- Speaker specification:40mm (dual NdFeB 16 core) 4Ω /5W
- TF card : support : 32G
- Audio playback format: MP3 / WMA / WAV /FLAC
- Bluetooth transmission distance: 10M
- With antenna jack ---Supports plugging in an external antenna to improve FM SW!
- With 3.5mm headphone jack---Enjoy radio anytime and anywhere
Unit Size
- 166 x 92 x 47 mm (W x H x D)
- Including battery 289g（ Excluding battery 237g ）
Small size, easy to carry, very suitable for home, travel, camping! Let you enjoy the wonderful listening time at any time.
Package Contents
- 1 x XHDATA D-109WB Radio (with rechargeable 18650 battery)
- 1 x Type-C charging cable
- 1 x English manual
With its comprehensive range of features and high-performance capabilities, XHDATA D-109WB FM/MW/LW/SW/NOAA Global Band High Performance Professional Radio is a reliable companion for outdoor adventures, emergency situations, and everyday listening.
