Product Specifiations
Product Name: P5 Outdoor LED module
Module Size: 320mm*160mm*18mm
Refresh Frequency:≥3840Hz
Pixel Pitche(mm): 5mm
Unit Board Resolution:64*32=2048Dots
Pixel Density: 40000Dots/㎡
Brightness Range(cd/㎡): 5500-6000 cd/㎡
Drive Method: 1/8Scan
Lamp Type: SMD1921
Module Voltage: 4.5-5V
Unit Power:≤41.5W
Maximum Current:8±0.3A
Frame Frequency:60Hz
Display Voltage:110/220V
Optimum Sight Distance: ≥5M
Max Power(W/㎡): 810W/㎡
Average Power(W/㎡): 325W/㎡
Port Type:HUB75
Operating Temperature:-20~+50℃
Working Humidity(RH):10-90％
Life Span: ≥100000Hour
Real Shot
