P5 Indoor Matrix Panel RGB 320x160 Module LED Full-Color Display SMD2121

We do not recommend using WF1, WF2, or WF4 for this P5 because using this type of control card may result in insufficient brightness

P5 Indoor Matrix Panel RGB 320x160 Module LED Full-Color Display SMD2121 Light 64x32 Pixels 16Scan Screen Advertising Video Wall

Note:

1. The PCB board and led module frame box will update have each batch, so the led module picture not same as picture. Thanks

2. Our companysupport customized, like led lamp (Kinglight, Nationstar), IC (MBI5124 etc). if you need, you can

send request to manager (whatsapp/wechat: +86 15874032641), i will confirm and give you price.MOQ:100PCS. Thanks

Q1:How to choose a proper led screen for your need?

A:You just need to think of 3 simple questions when you choose a led screen by yourself.

1.Will you use it indoor or outdoor?

2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in

one place forever)?

3.what is the appoximate size of the led screen you would like to purchase?

Q2:Which pixel pitch should i choose?

 A:There are many different pixel pitch from 1.667--20,25,30mm, there is a roughly principle-usually small pixel(1.667mm-10mm) used

for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen(for example high way huge advertisement).

Q3:Which control system should i choose?

A:There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than

20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate

is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.
