Hotcams Camshaft - Stage 1 4011-1

Slide Slide Slide Slide
$252.76
Machine Type
ATV
Model
Camshaft - Stage 1
Type
CAMSHAFT
UPC
714205043518
Brand
Hot Cams
Manufacturer Part Number
4011-1
condition
New
Founded in 2001 as the first manufacturer of aftermarket, performance billet camshafts for the dirt bike and ATV market. Today Hot Cams manufacturers almost 250 unique camshaft profiles in its Urbandale, Iowa facility.

Stage 1: Single (or dual-cam) motor.
True drop-in cam.
No valve spring change needed.
Improved acceleration, more bottom end, and no top-end loss.
Detailed Specifications:

Exhaust duration (degrees at 1 mm): 249.00.
Exhaust lift (mm): 9.40.
Exhaust lobe center (degrees): 106.00.
Exhaust valve lash (mm): 0.25.
Intake duration (degrees at 1 mm): 254.00.
Intake lift (mm): 8.50.
Intake lobe center (degrees): 106.00.
Intake valve

Hotcams Camshaft - Stage 1 4011-1

Founded in 2001 as the first manufacturer of aftermarket, performance billet camshafts for the dirt bike and ATV market. Today Hot Cams manufacturers almost 250 unique camshaft profiles in its Urbandale, Iowa facility.

  • Stage 1: Single (or dual-cam) motor.
  • True drop-in cam.
  • No valve spring change needed.
  • Improved acceleration, more bottom end, and no top-end loss.

Detailed Specifications:

  • Exhaust duration (degrees at 1 mm): 249.00.
  • Exhaust lift (mm): 9.40.
  • Exhaust lobe center (degrees): 106.00.
  • Exhaust valve lash (mm): 0.25.
  • Intake duration (degrees at 1 mm): 254.00.
  • Intake lift (mm): 8.50.
  • Intake lobe center (degrees): 106.00.
  • Intake valve lash (mm): 0.20.
  • Notes: Uses stock auto-decompression mechanism. Uses stock valve springs.
