• Send from USA,2-8 days delivery with tracking.

•


• EPEVER MPPT Solar Charge Controller,Tracer-A Seres.

• 40A/30A,12V/24VDC AUTO,

• Max 100V PV Input,With LCD display.

• Battery : LiFePO4 Lithium Battery And Lead Acid Battery

• Remote meter MT50.

•


• Package include :

  1,Controller

  2,Meter MT50

  3,Cable

•


•


• About this item

• Negative Grounding Design and advanced MPPT control algorithm make it charging efficiency no less than 99.5%, it maximize the charging power as a way of saving the energy.

• 100V Max PV Input allow you connect 4 x12V solar panel connecting in series, it minimize the charging current on solar panel 's leads to save power loss.

• Compatible with LiFePO4 & Li(NiCoMn)O2 Batteries, with built in preset lithium battery type, it's not require setting charging parameters for lithium batteries.

• Work with both 12v battery system and 24v battery system, It allows 24V Solar Panels (or Even Higher Voltage) Charging 12v/24v Battery

• Standard Modbus communication protocol with RS485 interface , it can be monitored by cellphone APP(eBox required) , PC Software and MT50 remote meter

•


• Product Feature

• MPPT tracking efficiency above 99.5%

• Maximum charge conversion efficiency as high as 98%

• Support lead-acid and lithium-ion batteries

• Multiple load work modes

• Charging power and current limitation

• High-temperature charging power derating function

• Standard Modbus communication protocol with RS485 interface

• Real-time energy statistics

• Negative Grounding Design

• 100V PV input allows more panels connected in series

• Work with LiFePO4 Lithium Battery And Lead Acid Battery

•


• Something you should know for Lithium Batteries Charging

• • When a lithium-ion battery is used, the system voltage cannot be identified automatically, please confirm the battery system voltage before installation.

• • When you choose lithium battery as a battery type, the temperature compensate coefficient would be 0, and cannot be changed.

• • This MPPT solar charge controller can work under full load in the ambient temperature range. when the internal temperature reach 81℃, the power reduction mode will be turned on.

• • Lithium battery type can ONLY be set on a cellphone app or "solar station monitor" PC software.

• Electronic protections:
  • PV reverse polarity protection
  • PV short circuit protection
  • PV over current alarm protection
  • Battery overcharge protection
  • Battery over discharge protection
  • Battery reverse polarity protection
  • Load short circuit protection
  • Load overload protection
  • Overheating protection

•


• Model	30A	40A
  Nominal system voltage	12V/24VDC auto work
  Rated  battery current	30A	40A
  Rated  load current	30A	40A
  Max. PV open circuit voltage	100V
  Max. battery  voltage	32V
  Max. PV input power	390W  (12V)	520W  (12V)
  	780W  (24V)	1040W  (24V)
  Equalize charging voltage	Gel: 14.2V,  Sealed: 14.4V,  Flooded: 14.6V
  Boost charging voltage	Gel: 14.2V,  Sealed: 14.4V,  Flooded: 14.6V
  Float charging voltage	Gel /Sealed /Flooded: 13.8V
  Low voltage reconnect voltage	Gel /Sealed /Flooded: 12.6V
  Low voltage disconnect voltage	Gel /Sealed /Flooded: 11.1V
  Self-consumption	≤20mA(12V)  ≤16mA(24V)
  Grounding	Negative ground
  Temp. compensation	-3mV/℃/2V
  Communication Port	RS485 / RJ45 interface
  Working temperature	-25℃～+45℃
  Storage temperature	-35℃～+80℃
  Humidity	≤95% N.C.
  Enclosure	IP30
  Overall dimension	228x164x55mm	252x180x63mm
  Terminal	10mm2	10mm2
  Net weight	1.2kg	1.9kg

•


•


Remote Meter MT50 :

• Features:


  •  Automatic identify  the controller, and display relevant parameter data
  •  Large-screen informative LCD displays all the operating data and system working status
  •  Simple and convenient operation
  •  Real-time alarm of failure information
  •  Longer communication distance based on RS485
  •  Diversified load control modes : Manual Control, Light ON/OFF, Light ON+ Timer, Time Control
  •  Battery type selection: Gel, sealed, flooded and User(programable)
  •  Programmable parameters
  •  Energy  statistics display function

Specifications :

Self-consumption :   Backlight and acoustic alarm on<65mA
