Delphi Weather Pack Terminals Kit 14-16 AWG

$7.3
Brand
Delphi
Country of Manufacture
United States
Finish
Black
UPC
NA
condition
New

Delphi Weather Pack Terminals Kit 14-16 AWG, 16-14 AWG

Description:

Weather-Pack connector kits offer an affordable, waterproof connector that is ideal for automotive, marine, racing, industrial applications. For 16-14 AWG wire.

Delphi Weather Pack Connectors are environmentally sealed electrical connections designed to withstand exposure to extreme temperatures and moisture. Terminals are tin plated and have special core wings which allow crimp-only connections, eliminating the need for solder. The connector and cavity seals are triple-ribbed and made of self-lubricating silicone. Cavity plugs are available to fill unused cavities

Specifications:

Wire Gauge: 14 - 16 AWG
Current Range: 0 – 20 amps
Temperature Range: - 40°C to 125°C
Resistance: <10mΩ @ 50mV
Voltage Drop: <3.0mV/amp

Included:

10x Female terminal
10x Male terminal
20x Terminal seals
