Complete Aluminum Cylinder Heads SBF FORD GT40 289 302 351W 175cc 62cc 2.02/1.60

Slide
$721.05
Type
281 Cylinder Head : 281 Cylinder Head [Assembled]
Interchange Part Number
P3036/P3037
Brand
Generic
condition
New
Brand:AT Racing World
Part Number:FF281.1004
Part Type:Cylinder Heads

Cylinder Head Style:Assembled
Cylinder Head Material:Aluminum
Cylinder Head Finish:Natural
Combustion Chamber Volume (cc):62 cc
CNC-Machined Combustion Chamber:No
Intake Runner Volume (cc):175 cc
Exhaust Runner Volume (cc):n/a
CNC-Machined Intake Runner:No
CNC-Machined Exhaust Runner:No
Intake Port Shape:Rectangular
Intake Port Location:Standard
Exhaust Port Shape:Square
Exhaust Port Location:Standard
Spark Plug Style:Standard
Comp. Valve Job:No
Intake Valves Included:Yes
Intake Valve Diameter (in):2.020 in.
Exhaust Valves Included:Yes
Exhaust Valve Diameter (in):1.600 in.
Valve Springs Included:Yes
Maximum Valve Lift (in):0.550 in.
Outside Diameter of Outer Spring (in):1.450 in.
Damper Spring Included:Yes
Number of Springs Per Valve:Dual
Retainers Included:Yes
Retainer Material:Chromoly steel
Locks Included:Yes
Lock Style:10 degree
Valve Stem Seals Included:Yes
Valve Stem Seal Style:Positive stop
Rocker Arm Studs Included:No
Rocker Arms Included:No
Rocker Arm Nuts Included:No
Guideplates Included:No
Valve Cover Mounting Style:Perimeter Bolt
Accessory Bolt Holes Drilled:Yes
Intake Valve Angle:20 deg.
Exhaust Valve Angle:20 deg.
Valve Guides Included:Yes
Valve Guide Material:Bronze
Valve Seats Machined:Yes
Valve Seat Machine Style:3-angle
Valve Seat Material:Ductile iron
Steam Holes Drilled:No
Oiling Style:Through pushrod
Machined for O-Ring:No
Heat Crossover:No
Quantity:Sold as a pair.
CalculatorCompression Calculator




Assembly Specifications Max Lift: .550 Coil Bind: .740 Intake Install: 130lbs @ 1.8 Exhaust Install: 130lbs @ 1.8 Closed Sear Pressure: 110lbs Open Seat Pressure: 300lbs
