C&K 1201 DPDT Miniature Slide Switch - 20 V AC / DC - PC Board Mount - 0.4 VA

Slide Slide Slide Slide Slide Slide Slide Slide Slide Slide Slide Slide
$6.95
Number in Pack
1
MPN
1201
Item Width
11.4 mm
Item Length
12.7 mm
Item Height
9 mm
Model
1201
Coil Voltage
20 V
Current Type
AC/DC
Contact Configuration
Double Pole Double Throw (DPDT)/3-Way
Operation Method
On/Off/On
Brand
C&K
Fuse Type
Switch
Color
Silver
Mounting Style
PCB
Termination Type
PC Pin
Switch Style
Slide
Type
Tiny Slide Switch
condition
New
C&K 1201 DPDT Miniature Slide Switch - 20 V AC / DC - PC Board Mount
  • Miniature slide switch
  • Manufacturer: C and K
  • Series: 1201
  • DPDT contacts ( ON - NONE - ON )
  • Rating: 0.4 VA - 20 V AC/DC max.
  • 6 connecting gold plated pins for PC board mounting
  • Epoxy terminal seal
  • Black nylon lever - stainless steel housing over red diallyl phthalate body
  • Dimensions (W x D x H): 12.7 mm x 11.4 mm x 9 mm
  • Weight: .1 oz (3 g)
  • Typical applications: Test and measurement equipment, telecommunications, computers and peripherals, etc.
