BUDWIG HQ-1
DIPOLE OR INVERTED V ANTENNA CENTER CONNECTOR
|
|
ANTENNA
CENTER CONNECTOR
BUDWIG HQ-1 |
|
Designed for durability and light weight, this connector
provides a coax SO-239 socket for accepting PL-259 feed line
connector. The one piece molded body offers weather tight
construction and provides a drip shield to protect the coax
fittings.
-
Note: This is not PVC
pipe fittings with eye hooks that will pull apart or
leak when stressed or exposed to harsh weather.
-
The center connector
will not crack or become brittle when exposed to
sunlight.
-
No internal or
external nuts to come loose or corrode.
-
The center connector
is a one piece molded body and is designed for high
stress (up to 18,000 PSI tensile strength).
-
DESIGNED FOR FULL
LEGAL POWER!
|
|
Compressive Strength |
30,000 psi |
|
Flexural Strength |
34,000 psi |
|
Dielectric Strength |
500-600V |
|
Effect of Sunlight |
None |
|
Material |
ABS 20% Glass Fiber
Filled |
|
Tensile Strength |
18,000 psi |
|
Effect of Weather |
None |
|
Service Life |
Indefinite |
|
Color |
Green (Olive Drab)
|
|
|
