GX Series
SPECIFICATIONS
LED Type: 7035CSP (75 Mil Larger LED)
Efficacy(2/pcs): 120W
LED Quantity(Per Bulb): 6pcs (Single Beam Socket)
Effective Lumen(2/pcs): 25000 LM
Current Draw: 4.5A (±0.2A）
Operating Voltage: 9-13V
Color: 6500K Natural White
Material: Aviation 6063 Aluminum
Heat Dissipation Mode: Fan Dissipation
LED Lifetime: 50000 Hours
Waterproof: IP68
Ambient Operating Temperature: 45 Celsius Degree~150 Celsius Degrees
F22 Series
SPECIFICATIONS
LED Type: 3570CSP (55mil larger LED)
Efficacy(2/pcs): 110W
LED Quantity(per bulb):12pcs (Single beam socket)
Effective Lumen(2/pcs): 24000 LM
Current Draw: 3.75A (±0.2A)
Operating Voltage:9-13V DC
Color: 6500K Cool White
Material: Aviation 6063 aluminum profile
Heat Dissipation Mode: Fan dissipation
LED Lifetime: 50000 hours
Waterproof: IP68
Ambient Operating Temperature: 45 celsius degree~150 celsius degrees
F15 Series
SPECIFICATIONS
LED Type: CSP 3570
Efficacy(2/pcs): 90W
LED Quantity(per bulb): 16pcs (Single beam socket)
Effective Lumen(2/pcs): 20000LM
Current Draw: 2.5A
Operating Voltage: 9-12V
Color: 6500K Cool White
Material: Aviation 6063 Aluminum Profile
Heat Dissipation Mode: Fan dissipation
LED Lifetime: 50000 hours
Waterproof: IP68
Ambient Operating Temperature: -40 celsius degree -150 celsius degree
F2 Series
SPECIFICATIONS
LED Type: CSP 1860
Efficacy(2/pcs): 52W
LED Quantity(per bulb):12pcs (Single beam socket)
Effective Lumen(2/pcs): 10000LM
Current Draw: 2.1A
Operating Voltage: 9-12V
Color: 6500K Cool White
Material: Aviation 6063 Aluminum
Heat Dissipation Mode: Fan Dissipation
LED Lifetime: 50000 hours
Waterproof: IP68
Ambient Operating Temperature: -40celsius degree - 150celsius degree
F-16 PLUS Series:
Specifications:
Plug Type: H11=H9,Single Beam
LED Type: CSP 3570 Automotive Grade
Efficacy(2/pcs): 70W
LED Quantity: 12pcs (single light) 24pcs (twin light)
Raw Lumen(2/pcs): 180000 LM
Current Draw: 2.5 A
Operating Voltage: 9-32V
Color:Natural White
Color Temperature : 6500K
Material: Aviation 6063 Aluminum
Heat dissipation mode: Fan Dissipation
LED Lifetime: 50000 hours
Waterproof: IP68
Ambient Operating Temperature: 45 celsius degree~150 celsius degree
Canbus：Yes Fits 98% of vehicles: In-built fully upgraded Canbus.
Some sensitive cars may flicker after installed(not quality issue), specific canbus decoders are needed.
Features:
-Upgraded version of F-16 Plus series, CSP3570 LED chips, 6000K white, high efficient luminance output.
-0.04inch slimmest side designed, ultra-thin lampstandard design to provide wider viewing angle.
-Compact all-in-one integrated design, external drive, built-in canbus, self-contained decoding to avoid error codes.
-Aviation aluminum with high thermal conductivity, built-in ball-bearing fan with 12000R/Min, maximum heat dissipation.
-Built-in IC, EMC tech avoid current frequency noise caused by electromagnetic interference.
-All round water proof safe lighting IP68.
SPECIFICATIONS:
LED Type: 7535 CSP LED Chip
Efficacy(2/pcs): 100W
LED Quantity(per bulb):
12pcs (Single beam socket)
24pcs (High&Low Dual beam socket)
Effective Lumen(2/pcs): 28000LM
Current Draw: 4.17A (±0.2A)
Operating Voltage: 9-13V
Color: 6500K Cool White
Material: Aviation 6063 Aluminum Profile
Heat Dissipation Mode: Fan Dissipation
LED Lifetime: 50000 hours
Waterproof: IP68
Ambient Operating Temperature: 45-celsius degree~150 celsius degrees
MAIN FEATURES
1:1 MINI SIZE, 5-MINS EASY INSTALL
1:1 mini size is the same as halogen bulbs, with higher compatibility, avoiding any installation problems, and can be quickly installed within 5 minutes.
Perfectly fit into the car housing and factory sockets without modification, dust cover damage, or narrow space trouble.
600% BRIGHTER THAN HALOGEN
Equipped with double-sided 7535CSP LED chips with 600% brighter than halogen bulbs, irradiation distance up to 22000FT.
Each set light outputs 28,000LM and 6500K cool white ensuring vision for enhanced visibility and clarity.
PERFECT BEAM PATTERN
The same light filament position perfectly simulates the factory halogen bulbs’ beam pattern and comes out with 360° full-angle illumination.
No dark spots or shadow areas, no blinding or glare to oncoming drivers, and no scattered light problems to ensure safety.
OUTSTANDING COOLING PERFORMANCE
Made of a 6063 aviation aluminum lamp body, combined with a single copper pipe and circular copper pipe design, equipped with a 15,000 RPM turbo cooling fan, which helps to dissipate the heat generated by chips quickly and effectively, extending the bulb's lifespan up to 50,000 hours.
BUILT-IN CAN-Bus
New upgraded driver system, improves the compatibility with 99% of vehicle's computer system without error.
Some sensitive car brands like for Mercedes-Benz, BMW, Volvo, Dodge, Ford Fusion, Ford Focus, Ford Escape, etc, may flicker after installation (not a quality issue), specific Canbus decoders are needed.
Package Included:
2 x H11/H9 LED Car headlights (H9 is the same as H11)
1 x English installation manual
