Air-Operated Double Diaphragm Pump 2" Inlet Outlet 140GPM Aluminum Alloy

Slide Slide Slide Slide Slide Slide Slide Slide Slide Slide Slide Slide
$431.99
Brand
Unbranded
MPN
YBGMBQBY4-50L0001
Type
Diaphragm pump
Suction
0-10 m (0-32.8 ft)
Outlet Port
2 inch (50 mm)
Ball Material
Acetal
Inlet Port
2 inch (50 mm)
Air Inlet Size
NPT 1/2 inch (12.7 mm)
Manifold Connection
Single
Diaphragm Material
Nitrile
Max Flow Rate
75 GPM
Self-Priming Dry
3 m (10 ft)
Body Material
Aluminum Alloy
Max Suspended Solids
3 mm (1/8 inch)
Valve Type
Ball
Model
QBY4-50L
Self-Priming Wet
4.6 m (15 ft)
Check Seat Material
Polypropylene
Max PSI
120 psi
Average Air Consumption
38 CFM
Max Head
84 m (275.59 ft)
condition
New
  • Premium Double Nitrile Diaphragms: Our air-operated double diaphragm pump adopts nitrile diaphragms, durable, corrosion-proof, and long-lasting. Max. Temperature: 150 ℉/66 ℃; Max. Pressure: 120 psi; Max. Flow Rate：75 GPM; Max Head Lift：275.6 ft/84 m.
  • Sturdy & Leak-proof Construction: The diaphragm pump housing is made of aluminum alloy material, bolted against leakage, sturdy, and corrosion-proof for long-time use.
  • Excellent Air-operated Performance: Inlet/Outlet Port Size: 2 inch; Air Inlet Size: FNPT 1/2 inch. A high-quality glyd ring, the double-acting sealing, strengthens air performance.
  • Unique & Professional Designs: Our double diaphragm pump features an externally available air distribution system. The modular air valve is stainless. This low pulsation air valve provides smooth and rapid changeover for increased efficiency and minimizes downtime.
  • Wide Applications: This diaphragm pump can handle various fluids, such as waste oil, alcohol, hydraulic fluid, gasoline, diesel, detergent, drink, and so on. It is widely used in many industries, such as petroleum, metallurgy, mining, coating, printing, water treatment, and automobile.

Key Features

  • Sturdy Aluminum Alloy Body

    The shell of the air-operated diaphragm pump adopts aluminum alloy construction, all bolted, solid, and corrosion-proof. Max. Temperature: 150 ℉/66 ℃; Max. Pressure: 120 psi.

  • Nitrile Double Diaphragm

    The self-priming pump features double nitrile diaphragms, which have high resistance to corrosion and aging. Max. Flow Rate：75 GPM; Max Head Lift：275.6 ft/84 m.

  • Professional Air-Operated Designs

    Our diaphragm pump is built to meet the international standard for reliable performance. Inlet/Outlet Port Size: 2 inch; Air Inlet Size: FNPT 1/2 inch.

  • Sealed Ball Valve

    It is easily accessible to ball checks and fluid caps for maintenance and repairs. In addition, the motor design delivers optimum air efficiency. An “Unbalanced" air valve ensures no-stalling during operation.

  • Handle Various Material

    This air-operated diaphragm pump can transfer many viscous and flammable fluids, including waste oil, alcohol, hydraulic fluid, gasoline, diesel, detergent, drinking water, and so on.

  • Versatile Uses

    The double diaphragm pump has applications in various industries like petroleum, metallurgy, mining, coating. printing, water treatment, automobile, etc.

Air-Operated Double Diaphragm Pump Aluminum Alloy Construction & Nitrile Diaphragm & 75 GPM Flow Rate Our self-priming diaphragm pump features an all-bolted aluminum alloy body and double nitrile diaphragms, sturdy and corrosion-proof, without leakage. Sealed ball valves and non-stall operation provides outstanding performance. It is perfect for transferring viscous and flammable fluids. Our top of the line self-priming diaphragm pump will ensure your operations are flowing smoothly.

Excellent Air-operated Performance

  • Unique & Professional Designs

Specifications

  • Model: QBY4-50L
  • Type: Air-operated Double diaphragm
  • Diaphragm Material: Nitrile
  • Body Material: Aluminum Alloy
  • Inlet/Outlet Port: 2 inch (50 mm)
  • Air Inlet Size: NPT 1/2 inch (12.7 mm)
  • Max Flow Rate: 75 GPM
  • Max Head: 84 m (275.59 ft)
  • Valve Type: Ball
  • Suction: 0-5 m (0-16.4 ft)
  • Max Suspended Solids: 3 mm (1/8 inch)
  • Average Air Consumption: 38 CFM
  • Self-Priming Dry: 3 m (10 ft)
  • Self-Priming Wet: 4.6 m (15 ft)

Package Content

  • 1 x Air-Operated Double Diaphragm Pump
  • 1 x Product Manual
