2Pcs AN6 Universal 90 Degree Swivel Hose End Fitting Adaptor For Fuel CPE Hose

Slide Slide Slide Slide Slide Slide Slide Slide
$9.34
Warranty
3 Months
Manufacturer Part Number
R811123
Size
6AN, 6AN
Type
Swivel
Color
Red&Blue
QTY
2PCS
Max Pressure
1000 PSI
Fitment Type
Direct Replacement
Angle
90 Degree
Material
6061-T6 Aluminum
Temp Range
-65
Thread Size
9/16"-18UNF
Nominal Hose ID
0.375"
Actual CPE Fuel Hose ID
0.34"
Brand
Racingcarpartshome
MPN
R811123
condition
New
Details
Description:
  • 100% Brand New
  • Color:Red&Blue
  • Made of High Quality Lightweight T-6061 Aluminum Material
  • Anodized Finish for Durability
  • High Performance Racing Fittings
  • CNC Machined
  • Enforced for heavy duty use
  • Work with all stainless braided and nylon braided hose
  • Universal Application for All Oil/ Fuel/ Water/ Fluid/ Air Line With Fitting
  • Professional Installation is Highly Recommended (No Instruction Included)
Package Included:
  • 2Pcs AN Degree Swivel Hose End
Installation Instruction:
  • Wrap masking tape over the area to cut to ensure a nice clean cut and prevent the braid from unravelling.
  • Clean cut the hose and clean away debris.
  • Clamp the fitting socket into the vise and insert hose into socket
  • Apply lube to nipple
  • Start hand threading the socket down onto the fitting. Be careful not to strip the threads when starting. Tighten the initial threads by hand being careful not to strip the threads when starting.
