1997-2003 Suzuki GSF1200S Repair Manual Clymer M353 Service Shop Garage

Status: In Stock

Condition: New

You will receive the repair manual shown.

Clymer Shop Repair Service Manuals are the ultimate do-it-yourself guide for motorcycle, ATV, snowmobile, and personal watercraft maintenance and repair. Each manual is based on a complete teardown and detailed rebuilding of the specific model it documents. This book covers all major vehicle systems and shows you exactly how to carry out routine maintenance, restoration and servicing using easy to follow pictures, instructions, and diagrams, allowing you to save time and money by doing the work yourself.

This repair manual contains the following sections:

CHAPTER ONE / GENERAL INFORMATION

CHAPTER TWO / TROUBLESHOOTING

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Safety checks / Maintenance intervals / Tires and wheels / Battery / Periodic lubrication / Engine oil and filter change / Air filter / Periodic maintenance / Non-scheduled maintenance / Engine tune-up / Spark plugs / Specifications

CHAPTER FOUR / ENGINE TOP END
Engine service notes / Engine principles / Cylinder head cover / Camshafts / Camshaft chain tensioner / Camshaft chain / Rocker arms / Cylinder head / Valves and valve components / Cylinder block / Piston and piston rings / Specifications

CHAPTER FIVE / ENGINE LOWER END
Servicing the engine in frame / Engine / Oil pump / Oil cooler / Oil pan, oil strainer and oil pressure regulator / Starter clutch and gears / Crankcase / Crankshaft / Camshaft chain and guides / Connecting rods / Break-in / Specifications

CHAPTER SIX / CLUTCH
Clutch / Clutch hydraulic system / Clutch master cylinder / Clutch release cylinder / Clutch hose assembly replacement / Bleeding the hydraulic clutch system / Specifications

CHAPTER SEVEN / TRANSMISSION AND GEARSHIFT MECHANISMS
Engine drive sprocket cover / Engine drive sprocket / External shift mechanism / Transmission / Internal shift mechanism / Specifications

CHAPTER EIGHT / FUEL, EMISSION CONTROL AND EXHAUST SYSTEMS
Carburetor operation / Carburetor service / Carburetor assembly (1996-2000 models) / Carburetor assembly (2001-on models) / Carburetor cleaning and inspection (all models) / Pilot screw / Throttle position sensor / Carburetor heater and thermoswitch (2001-on U.K. models only) / Carburetor separation / Float height adjustment / Throttle cable replacement / Starter (choke) cable replacement / Air filter housing / Fuel tank / Fuel shutoff valve / Fuel filter / Fuel level gauge / Crankcase breather system / Evaporative emission control system (California models only) / Purge control valves and charcoal canister (California models only) / PAIR system (California models) / Exhaust system / Specifications

CHAPTER NINE / ELECTRICAL SYSTEM
Preliminary information / Negative battery cable / Charging system / Alternator / Ignition system / Starting system / Starter / Starter relay / Lighting system / Switches / Relays / Electrical components / Combination meter / Fuel level gauge (1996-2000 models) / Fuel level gauge (2001-on models) / Horn / Fuse box / Main fuse / Wiring diagrams / Specifications

CHAPTER TEN / WHEELS, TIRES AND DRIVE CHAIN
Motorcycle stand / ABS models / Front wheel / Rear wheel / Rear coupling and rear sprocket / Front and rear hubs / Wheels / Tires / Tire repairs / Drive chain / Specifications

CHAPTER ELEVEN / FRONT SUSPENSION AND STEERING
Handlebar / Handlebar left grip replacement / Steering head and stem / Steering head bearing race replacement / Steering stem bearing replacement / Front fork / Specifications

CHAPTER TWELVE / REAR SUSPENSION
Shock absorber / Shock lever assembly / Swing arm / Bearing replacement / Specifications

CHAPTER THIRTEEN / BRAKES
Brake service / Front brake pad replacement / Front caliper / Rear brake pad replacement / Rear brake caliper / Front master cylinder / Rear master cylinder / Brake hose replacement (non-ABS models) / Brake hose and lines replacement (ABS equipped models) / Brake disc and ABS rotor / Bleeding the brakes / Rear brake pedal / Anti-lock brake system / Specifications

CHAPTER FOURTEEN / BODY AND FRAME
Seat and lock mechanism / Front fender / Front fairing / Rear frame cover / Side cover / Sidestand / Centerstand / Specifications

INDEX

WIRING DIAGRAMS

This repair manual covers the following vehicles:

2003 2002 2001 2000 1999 1998 1997 Suzuki GSF1200S
