Features
- 【Technical Specifications】4"，1HP, 110V, 10.3Amps , 60 Hz,1-1/4” NPT discharge. 6 Impellers；Fits in a 4" casing.
- 【Economy & Effective】37GPM max & 207ft head；33FT lengthy electric cord -allows for easy connection，; built-in controlbox;built-in check vavle;built-in thermal protection
- 【Outstanding Performance】Stainless steel body& thermoplastic impellers -industrial grade heavy duty - guarantees high durability and long-lasting use;
- 【Widely Application】 Perfectly convenient for use at home and for factory usage;can be implemented in different types of wells-ash pipe wells, steel pipe wells, or soil wells；Can be used for extracting water from reservoirs, canals, rivers, open water tanks and other water lifting works
- 【 Built-in Controlbox & Check Valve】This item is with a built-in control box, it is for thermal protection, short-cut protection and overload protection；
- 【NOTICE】Additional copper check valve is included.Effectively prevent water backflow causing damage to the pump
| Specificaton: |
|---|
| Motor: 1HP/0.75KW |
| Voltage: 110-120V/60Hz |
| Max Flow: 37GPM/2500GPH 7.5 m³/h |
| Max Head: 207 FT |
| Amp: 10.3 A |
| Power Cable: 33 FT w/US plug |
| Pump Diameter: 4 in |
| Phase: Single |
| Rev: 3420RPM |
| Internal Thread Diameter: 1 1/4" |
| Material: 304 Stainless Steel |
| Water temperature: 32 ~113℉ |
| Maximun Sand Content：0.25% |
| Number of Impeller：6 |
| Protection Grade：IP58 |
| Water PH：6.5-8.5 |
| Package included：1X Deep Well Pump 1X33 FT Power cord w/US Plug 1 x 1 1/4in to 1in Outlet 1 x Copper Check Valve 1X Hot melt adhesive accessories1X English Manual 1X Retail package |
1HP 110V w/304 Stainless Steel
- This stainless steel deep well pump features a built-in check valve and stainless steel material. As a result, our pump is highly corrosion-proof and rust-proof, providing you with an extended use time.
Powerful Motor
- Pure copper wire click, strong power, safe and durable1
- Copper wire coil,high Efficiency, better heat dissipation
- Providing you with efficient and stable pump work
High-Quality Motor & Rotor
- Stable
- Energy-saving
- Long-life
- High Efficiency
High Lift & Large Flow Rate
- Upgraded Impeller
- High Pressure-resistant
- Prolong Pump Life
- Sand-resistant
- Wear-resistant
33FT cord
- 33 FT Power Cord
- 2 wire pump with 3-Wire (2 wires + ground wire)
Coupling & Outlet
- Cast iron with electrophoretic paint.
- Easy to install and connect with the water pipe.
- 1 1/4inch NPT size
|
Pressure switch set @ 20/40 psi |
Pressure switch set @ 30/50 psi |
Pressure switch set @ 40/60 psi |
|
114 feet (max static water level) |
91 feet (max static water level) |
68 feet (max static water level) |
