Send from USA,2-8 days delivery with tracking.
Controller + Meter + Cable.
Overview:
Tracer-AN series controller, based on multiphase synchronous rectification technology (MSRT) and advanced MPPT control algorithm, with dual-core processor architecture and common negative design, has the features of high response speed, high reliability and high industrial standard. MSRT can guarantee very high conversion efficiency in any charge power, which sharply improves the energy efficiency of solar system; Advanced MPPT control algorithm minimize the maximum power point loss rate and loss time, to ensure the tracking efficiency, corresponding speed as well as high conversion efficiency under high or low power, so that in any situation, Tracer-AN products can rapidly track the maximum power point(MPP) of PV array to obtain the maximum energy of the panel. The limitation function of the charging power and current, and automatic power reduction function fully ensure the stability when works with oversize PV modules and operate under high temperature environment.
With the adaptive three-stage charging mode based on digital control circuit, Tracer-AN series controllers can effectively prolong the life-cycle of battery and significantly improve the system performance. The load, utility and generator auto-control relay output make it easy to connect other equipment. All-around electronic protections, including overcharging, over discharging, and PV reverse polarity protection, effectively ensure the safer and more reliable operation of the solar system for a longer service time. The isolated RS485 interface with standard MODBUS communication protocol makes it easy for customer to expand the application, greatly meet with different monitoring requirements, so that can be widely used for various applications, e.g. solar RV, household system and field monitoring, etc.
About Tracer-AN Series
Negative Ground 200V PV Input, Compatible with 12/24/36/48V Batteries (Lead Acid) Charging. Lithium Battery :LiFePO4/ Li(NiCoMn)O2,Only Solar Panel and Battery Connector Available
Dual RS485 Port (RJ45 Connector), it can be paralleled up to 8 units together linked by 8pin ethernet cable to make the data monitoring easy and accurate.
Battery Type Compatibility, Lead Acid: Sealed, Gel, Flooded and User define, Lithium Battery: LiFePO4/ Li(NiCoMn)O2 / User, Battery temperature compensation will make the charging progress efficiently.
Standard Modbus communication protocol with RS485 interface , to monitor or set the parameters by using the phone Apps, MT50 Meter and PC software
Product Feature
Epever MPPT Solar Charge Controller,Tracer-AN Series.
100A/80A/60A/50A,12V/24V/36V/48VDC Auto,
Max 200V PV Input,with LCD display.
Package :
Advanced MPPT technology & ultra-fast tracking speed, with tracking efficiency no less than 99.5%
Maximum DC/DC transfer efficiency is as high as 98.6%, full load efficiency is up to 98%
Advanced MPPT control algorithm will minimize the MPP loss rate and loss time
The accuracy of the recognition and tracking at the highest point of multiple-peaks MPP
Charging power and current limitation
High-temperature charging power derating function
Standard Modbus communication protocol with RS485 interface
Negative Grounding Design
200V PV input allows more panels connected in series
Support up to 8 units paralleled
Electrical Parameters:
Item
Tracer5420AN
Tracer6420AN
Tracer8420AN
Tracer10420AN
Nominal System Voltage
12/24/36/48VDC or Auto
Battery Input Voltage Range
8V～68V
Battery Type
Sealed/Gel/Flooded/User
Rated charge current
50A
60A
80A
100A
Rated charge Power
625W/12V
750W/12V
1000W/12V
1250W/12V
1250W/24V
1500W/24V
2000W/24V
2500W/24V
1875W/36V
2250W/36V
3000W/36V
3750W/36V
2500W/48V
3000W/48V
4000W/48V
5000W/48V
Max. PV open
200V (At minimum operating environment temperature)
circuit voltage
180V (At 25℃ environment temperature)
MPP Voltage Range
(Battery voltage +2V)～144V①
Tracking efficiency
≥98.0%
Conversion efficiency
≤99.5%
Temperature compensate coefficient
－3mV/℃/2V (Default)
Self-consumption
98mA/12V;60mA/24V;50mA/36V;46mA/48V
Grounding
Common negative
RS485 interface
RS485(RJ45)
LCD backlight time
60S (Default)
